Linear Motor System

Get a Price/Quote

MOQ : 1 Set

Linear Motor System Specification

Lubricating System
Maintenance-Free

Drive Type
Linear Drive

Motor Power
550 Watt

Size
Customizable

Noise Level
< 40 dB

Capacity
Up to 120 kg Load

Features
High Precision, High Speed, Energy Efficient

Surface Finish
Matte

Usage & Applications
Industrial Automation, Robotics, Packaging, CNC Machinery

Shape
Rectangular

Product Type
Linear Motor System

Material
Aluminum Alloy Body

Technology
Linear Motion Technology

Power Source
Electric

Power
550 W

Voltage
220 V AC

Pressure
Atmospheric

Surface Treatment
Anodized Finish

Dimension (L*W*H)
1200 x 100 x 250 mm

Weight
28 kg

Color
Silver/Grey

Enclosure Protection
IP54

Operating Mode
Continuous Duty

Travel Method
Magnetic Levitation Drive

Insulation Class
F

Control System
PLC Compatible

Mounting Type
Base Mount or Side Mount

Maximum Speed
2 m/s

Cooling Method
Natural Air Cooling

Ambient Temperature
0 40C

Stroke Length
600 mm

Position Repeatability
0.01 mm

Sensor Integration
Inbuilt Position Sensors

Cable Entry
Flexible Conduit

About Linear Motor System

Products Description

DMT developed Gripper System & Tool Changer with our own technology, and mainly 50 models of Grippers and patented Tool Changers.
- Lightweight, Compact type, Always in Stock.
- Quality and Durability Improvement

Product Features

Maximum Precision and Speed

With a remarkable position repeatability of 0.01 mm and a top speed of 2 m/s, this linear motor system delivers consistent accuracy for demanding industrial tasks. The magnetic levitation drive ensures smooth and silent operation under continuous duty, making it suitable for automation processes where reliability is paramount.

Versatile Mounting and Integration

Choose either base or side mounting to suit your installation requirements. Inbuilt position sensors and PLC compatibility streamline integration into existing automated setups, reducing commissioning time. The flexible conduit cable entry supports varied layout designs while maintaining protected electrical connectivity.

Durable and Efficient Design

Constructed with an anodized aluminum alloy body and rated IP54, the system resists dust and moisture, ensuring durability in various operational settings. The maintenance-free lubricating system and natural air cooling enhance energy efficiency and minimize operational downtime over extended use.

FAQ's of Linear Motor System:

Q: How does the magnetic levitation drive improve the linear motor system's performance?

A: The magnetic levitation drive enables non-contact, frictionless movement, which reduces mechanical wear, minimizes maintenance needs, and delivers exceptional positioning accuracy and speed in industrial automation.

Q: What are the recommended applications for this linear motor system?

A: This system is ideal for industrial automation, robotics, CNC machinery, and packaging applications where precise positioning, reliability, and high speed are critical requirements.

Q: When is it necessary to use the IP54 enclosure protection feature?

A: IP54 enclosure protection should be employed in environments where machinery is exposed to dust and splashing water to ensure reliable operation and prolong equipment lifespan.

Q: Where can this linear motor system be installed, and what mounting options are available?

A: The system can be installed in manufacturing facilities or automation lines, with flexible base mount or side mount options to accommodate space constraints and specific process needs.

Q: What makes the lubrication system maintenance-free?

A: The maintenance-free lubrication system utilizes sealed bearings and materials engineered for low friction, eliminating the need for regular manual lubrication and reducing downtime.

Q: What benefits does the inbuilt position sensor provide for operational accuracy?

A: Inbuilt position sensors enable real-time feedback to the PLC control system, enhancing position repeatability (0.01 mm) and ensuring precise movement for complex automation tasks.

Q: How does the system ensure energy efficiency during continuous operation?

A: With its efficient 550 W power rating, natural air cooling, and advanced linear motion technology, the system minimizes energy consumption while maintaining high-speed, continuous duty performance.
