ECO PV Inverter Ultralight Compact Easy O-M

Get a Price/Quote

MOQ : 10 Units

ECO PV Inverter Ultralight Compact Easy O-M Specification

Overheating Protection
YES

Insulation Material
High Grade Polymer

Mounting Type
Wall Mounted

Humidity %
0-95% RH, non-condensing

Surface Finish
Powder Coated

Shape
Rectangular

Power Factor
>0.99

IP Rating
IP65

Operating Temperature
-25C to +60C

Connector Type
MC4 Compatible

Feature
Ultralight, Easy O-M, High Efficiency

Efficiency
Up to 98.5%

Product Type
ECO PV Inverter

Application
Solar Power Generation

Protection Level
IP65

Frequency (MHz)
50 / 60 Hz

Rated Voltage
220-240 V

Energy Consumption
Low

Output Type
Single / Three Phase Output

Color
Grey

Dimension (L*W*H)
350 mm x 260 mm x 155 mm

Weight
8.5 kg

Phase
Single Phase

Input Voltage
120-480 V DC

Size
Compact

Connection Type
Terminal / Connector

No Of Poles
Single

Material
Aluminum Alloy

Noise Level
<25 dB

Surge Protection
Integrated

Standby Power Consumption
<1 W

Compliance Standard
IEC 61727, IEC 62116

Grid Connectivity
On-Grid

Max. PV Input Power
4500 W

Cooling Method
Natural Air Cooling

Max. Output Current
21 A

Display Type
LCD Digital Display

Maximum MPPT Voltage Range
120480 V

Communication
RS485 / WiFi

ECO PV Inverter Ultralight Compact Easy O-M Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Telegraphic Transfer (T/T)

Packaging Details
Export Standard Packing

About ECO PV Inverter Ultralight Compact Easy O-M

Product Description

240kW class (1M = 4 channels)
* Ideal for solar construction

* Highest efficiency and control technologies
- EURO efficiency is greater than 98.18%
- Maximum efficiency is 98.45%,
- MPPT efficiency is higher than 99.8%

* Modular power stack that can be removable and mounted
- Easy installation and maintenance

* Real-time monitoring and operation status analysis
- TCP-IP communication through Gateway.
- Web EMS, Mobile Web EMS that can be controlled and monitored on a computer.

* 10years free warranty

Company Profile

Our company focuses on new and renewable energy such as Solar, Wind, and ESS Business.
We provide one-stop service from development new technology through R&D Center to construction, structure fabrication, maintenance and safety management.
We do have our own technology of ECO Electric Power.
Our company won't stop developing and investing on new technologies based on R&D Center.
We will fulfill its promise to our customers by completing 100% of its responsibilities.

Ultralight & Compact Engineering

Designed for easy installation and space-saving integration, the ECO PV Inverter weighs only 8.5 kg with a slim rectangular shape. The lightweight aluminum alloy casing combines durability and portability, making it suitable for wall-mounted applications in limited spaces.

High Efficiency and Reliable Performance

Engineered for maximum energy conversion, this inverter operates at up to 98.5% efficiency and supports a wide MPPT voltage range (120480 V). The advanced cooling system prevents overheating, and integrated surge protection ensures safe operation in all conditions.

Smart Monitoring & Connectivity

Equipped with an LCD digital display for real-time monitoring and RS485/WiFi communication, users can track system performance and manage operations remotely. The inverter complies with IEC standards, supporting flexible connectivity for modern solar installations.

FAQs of ECO PV Inverter Ultralight Compact Easy O-M:

Q: How is the ECO PV Inverter installed and mounted?

A: The ECO PV Inverter is designed for wall mounting, utilizing a compact rectangular shape and lightweight aluminum alloy enclosure. It can be installed indoors or outdoors, thanks to IP65 protection, and connects easily using terminal or MC4-compatible connectors.

Q: What cooling method does the inverter use to prevent overheating?

A: This inverter employs natural air cooling, eliminating the need for mechanical fans. Its design facilitates effective heat dissipation, and the built-in overheating protection further safeguards the unit during high-temperature operation.

Q: When is the ECO PV Inverter recommended for use?

A: It is ideal for solar power generation in residential, commercial, or light industrial environments where grid connectivity is required. Its performance is optimized for climates with operating temperatures ranging from -25C to +60C.

Q: Where can this inverter be used, considering its protection and noise levels?

A: Thanks to its IP65-rated enclosure and low noise emission (<25 dB), the inverter can be installed in a variety of settings, including residential homes, offices, and outdoor installations, where durability and quiet operation are priorities.

Q: What process is involved in monitoring the inverters performance?

A: Users can monitor real-time system metrics such as output, voltage, and operating status through the integrated LCD digital display. Additionally, remote access via RS485 or WiFi enables data logging and performance management from compatible devices.

Q: What are the key benefits of using the ECO PV Inverter in solar power systems?

A: Key benefits include high efficiency (up to 98.5%), low energy consumption, seamless integration via RS485/WiFi, built-in surge and overheating protection, and a compact, ultralight form factor for simple installation and maintenance.
