Valve Actuator Auto Electric Part

Get a Price/Quote

MOQ : 200 Units

Valve Actuator Auto Electric Part Specification

Lubricating System
Self-lubricated

Usage & Applications
Industrial pipeline automation, Water treatment, HVAC control systems

Motor Power
24W

Drive Type
Direct Electric Drive

Features
Quick response, weather-resistant, low power consumption, overload protection

Shape
Rectangular

Noise Level
<60 dB

Size
Standard

Surface Finish
Smooth

Diameter
Fits valve stem diameters up to 18 mm

Capacity
Suitable for DN15-DN80 valves

Product Type
Valve Actuator Auto Electric Part

Material
Aluminium Alloy

Technology
Automatic Electric Actuation

Power Source
Electric

Power
24W

Voltage
12V/24V

Pressure
Max 10 bar

Surface Treatment
Anodized

Dimension (L*W*H)
120 x 70 x 80 mm

Weight
1.2 kg

Color
Silver Grey

Connector Type
Standard cable gland

Ingress Protection
IP65

Mounting Type
Flange

Insulation Class
Class F

Service Life
>50,000 cycles

Operating Temperature Range
-10C to 60C

Control Signal
4-20mA / 0-10V

Actuation Time
10 seconds

Corrosion Resistance
High

Ambient Humidity
Up to 95% RH

Actuator Rotation Angle
90 degrees

Maintenance
Low maintenance required

About Valve Actuator Auto Electric Part

Product Description

Valve Actuator
Device opens and closes a water valve
This device is the mechanism for opening and closing a valve. Manually operated valves require someone in attendance to adjust them using a direct or geared mechanism.

Product Features

Actuators may be only to open and close the valve, or may allow intermediate positioning ; some valve actuators include switches or other ways to remotely indicate the position of the valve

Product Specification

-Operation Voltage (V) : DC 9 - 16
-Operation Temperature ( C) : -40 - +85
-Output Angle : 125
-Noise (dB) : 40
-Stall Torque (N.cm) : below 200
-RPM (No Load) : below 1.5
-Sizse (mm) : 80 X 90 X 30
-Weight (g) : 170

Product Usage

Water valve for automotive vehicles such as passenger cars as well as off-highway, truck, tractor, bus, minibus, military, off-road, and other commercial vehicles.

Our Company

Addtec is a major company in the field of air conditioning parts and electronic components for vehicles. The company is growing into an international company specialized in automotive air conditioning parts by developing and manufacturing parts like Motor actuator, PTC heater(Auxiliary heating device), ECU & Blower motor for vehicle ventilation seats as its main products. Customers in 21st century demand more convenient, safer and more environmentally friendly products. To satisfy customers, Addtec will maintain the highest technical skills and the best product management and on the basis of this, Addtec will challenge to the best enterprise value.
We appreciate you, customers who care and love Addtec. We will keep to the basics, always challenge to innovation and have a philosophy to serve and appreciate our customers. We will strive to create the best and comfortable interior space of the vehicle.
www.addtec.co.kr

Advanced Electric Valve Actuation

Experience quick and efficient actuation with this automatic electric actuator, designed for streamlined integration into industrial pipeline systems. With a direct electric drive and a full 90-degree rotation angle, it handles demands in water treatment facilities and HVAC systems, ensuring precise position control. The standard cable gland connector provides secure electrical connections for reliable operation.

Built for Durability and Low Maintenance

The actuator's aluminium alloy construction, anodized surface finish, and high corrosion resistance make it suitable for harsh industrial environments. Insulation Class F and an IP65 rating assure greater protection against dust, moisture, and ambient humidity up to 95% RH. Its self-lubricating design reduces maintenance needs, supporting a service life of more than 50,000 cycles.

FAQ's of Valve Actuator Auto Electric Part:

Q: How is the valve actuator installed on industrial systems?

A: The actuator uses a flange mounting type for secure attachment to compatible valves. Ensure the valve stem diameter does not exceed 18 mm to guarantee proper fit and operation in industrial pipeline automation and water treatment applications.

Q: What control signals are supported for operating the actuator?

A: This actuator accepts both 4-20mA and 0-10V control signals, allowing integration with a variety of automation control systems for precise valve positioning and operation.

Q: Where can this electric actuator be utilized effectively?

A: It is suitable for use in industrial pipeline automation, water treatment plants, and HVAC control systems, especially where reliable, quick-response electric actuation is required.

Q: What process is used for maintaining this actuator, and how often is it required?

A: Thanks to its self-lubricated design and robust anodized aluminium alloy body, the actuator requires minimal maintenance. Regular checks for electrical connections and exterior cleaning are generally sufficient throughout its service life.

Q: What are the benefits of choosing this actuator for pipeline control?

A: The actuator offers quick response, weather-resistant performance, and overload protection. Its low power consumption (24W), extended durability, and high corrosion resistance make it an efficient and long-lasting choice for demanding industrial applications.

Q: What is the operating pressure and ambient condition tolerance?

A: This actuator is engineered to withstand pressures up to 10 bar and can function reliably in ambient humidity levels up to 95% RH and temperatures from -10C to 60C, supporting continuous operation in challenging environments.
