Vacuum Relief Valve(Vacuum Breaker)
Product Details:
- Installation Type Threaded / Flanged / Welded
- Thickness Custom as per design
- Features Pressure set spring, Leak tight sealing, Easy maintenance
- Diameter 12 mm - 50 mm or as required
- Form Valve-Fitting
- Material Grade SS304 / SS316 / Brass / MS
- Machines Type Process Equipment, Storage Tanks
- Click to View more
X
Vacuum Relief Valve(Vacuum Breaker) Price And Quantity
- 1 Unit
Vacuum Relief Valve(Vacuum Breaker) Product Specifications
- Depends on size, approx. 0.5 kg - 2 kg
- SS304 / SS316 / Brass / MS
- Valve-Fitting
- Vacuum Relief Valve (Vacuum Breaker)
- Round/ Cylindrical
- 12 mm - 50 mm or as required
- Custom as per design
- Pressure set spring, Leak tight sealing, Easy maintenance
- Threaded / Flanged / Welded
- Available in 1/2 inch, 3/4 inch, 1 inch, 2 inch (Custom sizes on request)
- Silver / Brass color / Customized
- Industrial Grade
- Protection from vacuum conditions
- Polished / Coated / Painted
- Chemical, Pharmaceutical, Food, Beverage, and General Industrial Applications
- Rated for standard vacuum relief as per size
- Stainless Steel / Brass / MS (as per requirement)
- Process Equipment, Storage Tanks
- Corrosion-resistant, Durable, Accurate pressure operation
Vacuum Relief Valve(Vacuum Breaker) Trade Information
- FOB, FCA, CIF, CFA etc
- Telegraphic Transfer (T/T)
- Yes
- Export Wooden Packing
- ISO 9001/14001:2008
Product Description
Product Description
The vacuum relief valves are normally closed. But when installed at points where water column separation can occur, both orifices open admitting air into pipeline, then instantly close to trap air and thereby cushioning re-joining of the water column. In this manner severe pressure surge/water hammer is prevented as the system returns to normal operation.
Product Features
- Vacuum Relief for piping system
- Prevent Water Hammer & Vortex Phenomena
- Prevent overflowing
- Increase efficiency of water transport in a piping
- Easily cleaning the inside of air valve
Product Specifications
Set Vacuum : - Minimum 150 mmH2O (0.213 psig, 0.015 kg/cm2) / Maximum 9000 mmH2O (12.8 psig, 0.9 kg/cm2)
Large orifice : From 1-in (25-mm) To 12-in (300-mm)
Flange : From 1/2-in (13-mm) To 12-in (300-mm)
- ANSI, NPT, PT flange connection is available. Other flanges are to be discussed with technical sales person.
Product Use
For critical applications where vacuum protection is a must or water column separation is predicted, a vacuum relief valve is used. The vacuum Relief Valve is mounted at critical pipeline, high points, penstocks, or tanks and allows for rapid inflow of atmospheric air to reduce vacuum conditions in piping systems
Reliable Vacuum Protection for Industrial Systems
Designed for maximum dependability, the vacuum relief valve acts swiftly to prevent vacuum buildup in process equipment and storage tanks. Standard vertical mounting and factory-set opening pressure deliver precise operation, ensuring your system remains safeguarded under varying conditions. Its robust construction and leak-tight PTFE, Viton, EPDM, or Neoprene seals make it suitable for critical industrial environments.
Customizable for Versatile Applications
Offered in a range of materials, sizes, and surface treatments, this vacuum breaker adapts to installation requirements in chemical, pharmaceutical, food, and beverage sectors. Choose between screwed, flanged, or welded end connections and benefit from packaging that meets both domestic and international export needs. Custom sizing and sealing solutions provide flexibility for unique applications.
Effortless Maintenance and Installation
Engineered for user convenience, the valve features a tool-free design for easy routine inspection and cleaning. Simple installation options-threaded, flanged, or welded-ensure seamless integration with existing systems. Its lightweight, compact build allows for straightforward handling and placement, minimizing downtime during maintenance or replacement.
FAQ's of Vacuum Relief Valve(Vacuum Breaker):
Q: How does the vacuum relief valve function in process systems?
A: The vacuum relief valve introduces air or gas into a system when a preset vacuum is detected, preventing damage that could be caused by negative pressure. It remains closed during normal operation and opens only at the factory-set opening pressure, typically between 50 mmWC and 800 mmWC.Q: What media and pressure ranges can this vacuum breaker handle?
A: This valve is suitable for use with air and various gases, operating reliably within a pressure range of 0.01 Bar to 10 Bar. Its robust construction and industrial-grade materials ensure dependable performance under these varying conditions.Q: When should a vacuum relief valve be installed?
A: A vacuum relief valve should be installed whenever there is a risk of vacuum formation in process tanks or pipelines, which could cause collapse or operational interruptions. It is essential in industries such as chemical, pharma, and food processing where consistent pressure is critical.Q: Where is the recommended mounting position for this valve?
A: The standard mounting position for this vacuum relief valve is vertical. This ensures optimal performance and accuracy in pressure relief response within your system.Q: What maintenance process is required for the vacuum relief valve?
A: Maintenance is straightforward due to the tool-free design. The valve can be easily disassembled for cleaning or inspection, helping maintain leak-tight performance and prolonging the life of the device without specialized tools.Q: How does seal type and material selection benefit specific applications?
A: With a choice of PTFE, Viton, EPDM, or Neoprene seals, the valve can be fine-tuned for different chemical or environmental resistance needs, ensuring compatibility and long service life in various industrial processes.Tell us about your requirement
